PolyMax PC-FR

---

RECOMMENDED SETTINGS

Nozzle Temperature:

250˚C – 270˚C

Printing Speed:

30 – 50mm/s

Bed Temperature:

90˚C – 105˚C

Chamber Temperature:

90˚C – 100˚C

Bed Surface:

almost any surface with a thin coat of MAGIGOO PC

Cooling Fan:

OFF

Based on 0.4 mm nozzle and Simplify 3D v.4.0. Printing conditions may vary with different printers and nozzle diameters

MECHANICAL PROPERTIES

Young’s Modulus:

2634 ± 182 (MPa)

Tensile Strength:

67 ± 4.5 (MPa)

Bending Strength:

96.6 ± 1.3 (MPa)

Charpy Impact Strength:

11.7 ± 1.3 (kJ/m2)

THERMAL PROPERTIES

Glass Transition Temperature:

N/A

Vicat Softening Temperature:

116˚C

Melting Temperature:

N/A

NOTES

Drying Settings:

80˚C for 8h

Recommended Support Materials:

PolyDissolve™ S2

Other:

When printing with PolyMax™ PC-FR it is recommended to use a heated chamber.

It is recommended to anneal the printed part right after the printing process to release the residual internal stress when not using a heated chamber.

Annealing settings: 100˚C for 2h
